PET Release Film Single Sided Silicone Coated for Adhesive Tapes and Labels

Short Description:

This PET Release Film is made of PET as the base material with a single-sided (or double sided) silicon coating. It exhibits stable release force and excellent flatness. This product finds wide applications in industries such as protective film, adhesive products, die-cutting pressing, demoulding, and MLCC (Multi-Layer Ceramic Capacitor) manufacturing. It provides effective isolation and protection, serving as a reliable solution for various applications.

Send email to us Download as PDF

Product Detail

Product Tags

Product Features

1.Completely eliminate the phenomenon of surface rainbow stripes.

2.High subsequent adhesion(readhesion) to prevent the influence of silicon transfer on products.

3.Multi-coating technology.

4.Production technology of solvent and solvent-free products.

5.Temperature curing and UV curing technology.

6.The products are completed in a thousand-grade clean room to ensure high cleanliness of products.

Product Technical Data

Thickness	12 um to 188um
Width	30 mm to 2500 mm
Inner Core Diameter	3 inch or 6 inch
Transparency	92%
Glossiness	85%to 90%
Heat Shrinkage Rate(150°C,30 minutes)	0to 1.5%
Elongation	120%to 140%
Tensile Strength	230 to 240 MPa
Peel Strength(30cm/min,180)	16g/inch
SAS	92%
